20ft Ablution Block

20ft Ablution Block

Arguably the most important portable building on site, the Ablution Block. With various configurations, you can rest assured your team has suitable facilities to release the load.

Key Features

  • Separate Male and Female toilets with individual access doors
  • Installed hot water system
  • ‘Plug and Play’ plumbing for quick and easy deployment
  • 15A single phase, with Australian certification
  • Windows with flyscreen and steel shutters for security and airflow
  • Fluorescent LED Lights and double GPOs

Product Details

SCF Ablution Blocks are insulated for optimum temperature control and are fitted with urinals, cubicles, hot and cold water, and functional windows to improve natural airflow. Separate male and female facilities are also available, and our ‘plug and play’ plumbing ensures quick and easy deployment.

Every Ablution Block comes with power and lighting, and various cubicle configurations to suit your workforce needs including two stalls with two urinals (male), single (male) or double (female) basin and vanity.

Built with the same high-quality materials as our standard containers and portable buildings, the SCF Ablution Block is a staple for busy sites that require amenities. Each unit is construction compliant with all Australian standards and the National Construction Code 2013.

Our construction range thrives in harsh environments. Built from steel (including steel doors) with high quality fittings, our units are designed to last so your site isn’t interrupted.

Options

  • Shower Block with triple bathrooms; three bathrooms with shower, toilet, basin, vanity, heat light, clothes hook and towel rack

  • Shower Block with double bathrooms and laundry room; two ensuites with shower, toilet, basin, vanity, heat light, clothes hook and towel rack, plus one laundry room with bench and fittings for laundry trough, washing machine and dryer

  • Custom modifications available to suit your needs

20ft Ablution Block Dimensions and Weight

A range of larger 40 foot Ablution Blocks are also available. Specifications may vary. Contact SCF for specific dimensions, layouts and options.

Internal
Length (mm) 5,770
Width (mm) 2,150
Height (mm) 2,440
External
Length (mm) 6,058
Width (mm) 2,438
Height (mm) 2,896
Weight
Tare (kg) 3,000
Payload (kg) 7,000
MGW (kg) 10,000

How is this container delivered?

Ablution Blocks are compact, meaning they won’t take up too much space on your site. Any cleared, level part of the site should fit an Ablution Block. How we access the site will depend on our method of delivery, but the following methods suit these units.

SCF Shipping Containers - Delivery Method - Tilt Tray

Tilt Tray

Tilt tray delivers a container off the back of the truck. Similar to a tow truck, the tray is mechanically lowered at an angle, and the container is slid off, with the truck moving forward at slow speed. This is the most common delivery method used for containers. Tilt trays are not suitable for sites with overhead power lines as the container height increases significantly when tilted.

SCF Shipping Containers - Delivery Method - Side Loader

Side Loader

Side loaders are used to transport our 20 foot and 40 foot shipping containers. This is the best delivery method for containers at sites that have limited space either in front or behind the area where the container is to be positioned. The container is unloaded between the two outrigger feet of the side loader, approximately half a metre from the side of the truck.

SCF Shipping Containers - Delivery Method - Hiab Crane

Hiab Crane

Hiab cranes lift containers from a mechanism located behind the truck's cabin. This is used for smaller shipping containers, usually up to 20 foot, or when there is limited space for a side loader or tilt tray. Using a crane means the container is easily positioned at an angle or up on a raised area. It can also be used to place containers over a fence or other obstacles.
